1. Distribution valve adopts the advanced S pipe value system,with good sealing performance,simple and reliable structure,and easy replacement of wearing parts;
2. S pipe is equipped with floated wearing ring, compensating attrition automaticly, good tightness.
3. The counterforce on specially designed “S” valve is received by hopper wall to assure the service life of goggle plate and cutting ring.
4. Outlet pressure is high, which satisfy the high building construction and long distance transmission requirements.
5. Hydraulic system adopts U return circuit, reversing is fast and efficient.
6. Hydraulic oil cooling adopts advanced air cooling system, it do not need connect water source and easy to use.
7. Reverse pumping function can facilitate cleaning the conveying pipe.
8. Automatic lubricant filling device can eliminate the trouble of manual filling and extend the service life of the parts with less abrasion in the lubricants.
9. Most electrical appliance components of electrical system are imported, and PLC for control system,with reliable working,strong adaptability,and wired remote control;
10.Electric case is equipped with wired remote control handle.
|Item||Unit||Electromotor series||Diesel series|
|Theoretic concrete delivery volume||M3/h||40||50||40||50|
|Theoretic concrete delivery pressure||Mpa||10||12||10||12|
|The type of distribution valve||-||S tube valve|
|electromotor(diesel) rated speed||r/min||1480||1480||2200||2200|
|Main oil pump||-||Japanese Kawasaki|
|Main cylinder di./pole dia. Stroke||mm||φ100/70×1000||φ125/80×1200||φ100/70×1000||φ125/80×1200|
|Diameter of delivery cylinder||mm||φ600×1000||φ200×1200||φ160×1000||φ200×1200|
|Capacity of hyfrulic oil tank||L||200||240||200||240|
|Max. delivery distance||Vertical||m||120||150||120||150|
